Declarative Schema in Magento 2.3 and Higher: A Comprehensive Review

Magento 2.3 Declarative Schema

In 2018, Magento introduced a new declarative schema feature that aims at eliminating excessive work and speeding up the installation and upgrade processes.

Before losing your head over this innovation, let’s first have a closer look at it and see whether its pros outweigh its cons.

Install and Update Scripts: How It Always Used to Be

Before the declarative schema release, Magento developers had to write the database scripts in PHP for every new module version.

The latest module version normally contains all the changes and updates in the module code. So upon installation, Magento would go through all the module versions and through all the updates till the final version is reached.

declarative schema magento

A basic example of the module versions

Such an approach caused a whole lot of mundane and useless work. Version 1.0.1 could feature “add column” and version 1.0.2 would have “remove column”. In this case, Magento has to go through all the versions and execute all the set commands, including the mutually exclusive ones.

While for installation, all scripts are executed in a loop (in the order of module registration), in case of the upgrade only those scripts that match the upgrading module version are executed. As a result, certain disadvantages appear that affect the performance of the system:

  • Turmoil in the system. The presence of different script types in the system leads to it being unstable and complex. One of the most common mistakes that many developers make is putting changes in the installation script instead of creating a new one. This leads to the changes being skipped.
  • The complexity of installation. It often happens that, due to incorrect installation, the final structure is not the same as the base definition. The reason for that is the table with initially incorrect structure.
  • Big chance of errors. There is no 100% chance that all relations between tables exist or that the table was not modified by an extension. So an error can easily occur if an extension tries to reference the table from a different database.
  • New versions call for script growth. You cannot remove old sections before adding new ones for the new versions. This leads to complex and lengthy code, which slows down the performance.

But everything is not so bad with the install and upgrade scripts. With this approach, the system works just fine – but just fine is not enough for you.

Declarative Schema: A Quick Overview

Because there is always room for improvement, Magento presented a declarative schema feature that seems to work like a charm.

In short, the declarative schema allows developers to declare the final and the system will adjust to it automatically. Another important thing: once the module is uninstalled, the data will be deleted.

No more lengthy scripts and data overload. Instead, the declarative schema brings the following advantages:

  • avoidance of missed/repeated SQL operations: developers will be able to install only what’s needed,
  • dry-run mode for installation testing,
  • : the declarative schema approach significantly saves time by moving from the current version to the final point,
  • support for rollbacks: developers will be able to revert to a previous version,
  • validation before installation,
  • modification of existing columns,
  • seems like a gift from above for the developers.

The process of converting your scripts to declarative mode is relatively easy. Here is what you need to do.

Converting the Upgrade/Install Scripts to the Declarative Schema

If you want to continue working on your module in a declarative mode, you can easily convert it by using the Schema Listener Tool.

Run one of these two commands to convert the script. The “-convert-old-scripts” are the arguments specified by developers.

bin/magento setup:install --convert-old-scripts=1
bin/magento setup:upgrade --convert-old-scripts=1

It’s important to mention that these commands only convert the schema to the declarative mode but the install/upgrade will not be executed.

Once done, you can continue working on the module in declarative mode.

What could go wrong?

The tool cannot convert everything in the Magento 2.3 script.

  • Custom DDL operations are ignored by the tool. It supports only DDL operations that are present in \Magento\Framework\DB\Adapter\Pdo\Mysql.
  • Raw SQL in InstallSchema or UpgradeSchema scripts are ignored.
  • DDL statements in the Recurring file won’t be transferred to the new schema because the file needs to run during each installation or upgrade.

These issues have to be fixed manually.

Safety First: How Declarative Schema Keeps Your Data Safe and Sound

When writing the install/upgrade scripts, developers cannot be 100% sure that everything is fine. There may be missing relations between tables or the table can be modified by another extension. All these issues lead to the occurring errors and time spent on error identification and fix.

Declarative schema takes care of that by providing a dry-run mode for installation testing.

To start the dry-run mode, run one of the following commands:

bin/magento setup:install --dry-run=1
bin/magento setup:upgrade --dry-run=1

Magento will then generate a log file in /var/log/dry-run-installation.log. This file will have information about whether everything is fine or if there is an error. During the dry run, there will be no changes to the system. This mode gives developers a chance to have an error-free installation from the start.

The rollback and data restore options

The declarative schema does exactly what you’ve written. This is a big advantage and, at the same time, the biggest flaw of the declarative approach.

The problem is: everybody can make a mistake. A developer can accidentally delete a column or other structural element. That would lead only to the data loss but to the error in the system.

What declarative schema offers is an option of safe installation and rollback. In this case, the system will store all the changes being made in a CSV file.

To start the safe mode, run the command:

--safe-mode=1

To perform the rollback, run (only used with the setup:upgrade command):

--data-restore=1

After that, run:

setup:upgrade --data-restore=1

In the safe mode, Magento will create a CSV file that will contain details about the destructive operation that occurred. Such operations are:

  • deleting a table,
  • deleting a column,
  • reducing column length,
  • changing column precision,
  • changing column type.

If any of these processes happen, developers will be able to track the change down and roll back to the previous version safely. The CVS files will be located in one of these locations:

Magento_root/var/declarative_dumps_csv/{column_name_column_type_other_dimensions}.csv

Magento_root/var/declarative_dumps_csv/{table_name}.csv

As for the rollback, the declarative schema allows a rollback to the previous version in case something goes wrong during the release.

A schema whitelist

You will not be able to run a declarative mode without creating a schema whitelist.For that, you need a //etc/db_schema_whitelist.json file that will store all the content added with declarative schema. To generate this file, run:

bin/magento setup:db-declaration:generate-whitelist [options]

Note: it is recommended to generate a new whitelist for every release for double-check purposes.

40 Hours of Magento Services. FOR FREE

Try our custom development, optimization, support, and design services. One week, free of charge, no strings attached.

An Expert View on the Declarative Schema

An innovative feature does not necessarily mean you should rush to use it right away. We consulted with our and asked what they think about the new feature.

In general, the declarative scheme is both awesome and troublesome.

Its biggest advantage is how it deals with the schema part and eliminates excessive processes. The declarative approach saves time significantly and frees developers from doing the extra work.

But the devil is in the details. The declarative schema does not process all the data that your module contains.

For example, in version 1.0.1 you added a column and added certain data to it. In version 1.0.2, you delete the column.

Now, with the imperative approach, you’d have to delete the unused data from the structural element manually.

But with a declarative approach, the system skips to the latest version automatically. However, it does not delete the data but tries to fit it in the existing scheme.

This may cause errors and needs to be fixed manually. Or developers have to check every new installation for the presence of excessive data.

So until Magento rolls out a feature that fixes this bug, it would probably be safer to use the imperative method. However, nothing stops you from trying the declarative scheme. Note that once the module is converted, you can’t go back to install/upgrade scripts.

If you need help with converting to declarative schema or have any other questions about Magento and its processes, get in touch, we'll be happy to provide you with professional !

Magento 2 Declarative Schema: FAQs

What Is the Magento 2 Declarative Schema?

Magento Declarative Schema is a feature that first appeared in Magento 2.3. Its goal is to simplify database management and schema changes. It allows developers to specify the final desired state of the database using XML files instead of writing complex PHP scripts. The system will automatically adapt to it without requiring repetitive tasks. This approach offers several benefits:

  • simplified maintenance;
  • automatic updates;
  • improved consistency;
  • version control.

What Is Declarative vs. Imperative Schema?

The primary distinction between declarative and imperative schemas is that declarative means the system can figure out instructions on its own. It tells the system what the final structure should look like, and the latter makes the necessary adjustments to achieve this state. In the imperative schema, the programmer dictates each step and instruction.

What Are the Data Types in Magento 2 Database Schema?

In Magento 2, the database schema supports a variety of data types, including INT, SMALLINT, TINYINT, BIGINT, BOOLEAN, VARCHAR, TEXT, CHAR, DATE, DATETIME, TIMESTAMP, FLOAT, DECIMAL, BLOB, ENUM, SET.
